Skills

---

Over 20 years as a PCB designer,

Proficiency in all aspects of PCB design:

PCB design of high density, high speed, multilayer complex boards (12-18 layers), 10-15K pads

Back to back, large BGA pin counts placement, and routing, using blind & buried vias, laser Vias,

Placement & routing, large connector pin counts/fine pitch connectors.

Manual, and Auto routing, Controlled impedance routing of all types of technologies:

RF, Analog Digital routing over split-planes, Hi-Speed, wireless/Cellular, PCI-express, SCSI, Atca

I/O routing, ECL, Video Interface, Memory Routing, Power Supply, high voltage

Extensive knowledge in constrains manager:

Differential pairs, I2C match length, Clk signals Backplane, mother/ daughter boards,

Ability to review a bill of material & locate the necessary footprints

Support the schematic symbol/PCB footprint library utilizing Capture CIS

Upload and debug schematic capture into Allegro platform

Placement, using Capture to Allegro CrossProbe, Knowledge in RF placement

Implementation of constraints in OrCad capture,

Calculating control impedance, stack up building, using Polar

Produce production files, for PCB manufacture, and assembly, including ODB++

Checking for short nets and disconnected nets in PCB using Cam-350

Ability to converse with Pcb/assembly personal and supplying answers

Building panels for reflow and wave soldering

Maintenance of all mentioned software
